Проходные клеммы отличаются своей малогабаритной конструкцией и оптимальной технологичностью. Благодаря
фронтальному подключению этот модельный ряд предоставляет при монтаже дополнительное пространство
между кабельными каналами.
Двойной канал для перемычек обеспечивает реализацию индивидуального шунтирования цепи посредством штекерных
перемычек. Для контроля и маркировки предусмотрены соответствующие принадлежности.
Для распределения потенциала клеммы с тремя зажимами предоставляют малогабаритную альтернативу стандартным
проходным клеммам. Часто на практике необходимо подвести три провода к одной клемме, это требование реализуется в варианте с тремя зажимами без дополнительных клемм и перемычек.
При помощи двойного зажима проходных клемм с четырьмя зажимами четыре провода без проблем присоединяются к
одному и тому же потенциалу. Поэтому варианты с четырьмя зажимами применяются в качестве компактных
распределителей потенциала.
Завершают серию клеммы PE, имеющие форму аналогичную проходным клеммам. Безупречное механическое и
электрическое контактирование с несущей рейкой обеспечивается простым защелкиванием клеммы на эту рейку.
Клеммы PE выполняют все требования стандартаМЭК 60947−7−2:
• низкие переходные сопротивления
• нержавеющие зажимы
• желто−зеленый цвет корпуса
• дополнительная возможность маркировки
| Код | Заказной номер | Описание | Вес (кг) | Заказать |
|---|---|---|---|---|
| 123752 | 8WH2000-0AE00 | feed-through terminal with spring connection, section: 0.14 - 1.5 mm2, width: 4.2 mm, color: gray | 0.009 | Заказать |
| 123753 | 8WH2000-0AE01 | feed-through terminal with spring connection, section: 0.14 - 1.5 mm2, width: 4.2 mm, color: blue | 0.005 | Заказать |
| 123754 | 8WH2000-0AE02 | feed-through terminal with spring connection, section: 1,5 sqmm, width: 4,2 mm, color:red | 0.005 | Заказать |
| 77247 | 8WH2000-0AE03 | feed-through terminal with spring connection, section: 1,5 sqmm, width: 4,2 mm, color:green | 0.005 | Заказать |
| 77248 | 8WH2000-0AE04 | feed-through terminal with spring connection, section: 1,5 sqmm, width: 4,2 mm, color:orange | 0.005 | Заказать |
| 77249 | 8WH2000-0AE05 | feed-through terminal with spring connection, section: 1,5 sqmm, width: 4,2 mm, color:white | 5 | Заказать |
| 77250 | 8WH2000-0AE06 | feed-through terminal with spring connection, section: 1,5 sqmm, width: 4,2 mm, color:yellow | 5 | Заказать |
| 123755 | 8WH2000-0AE08 | feed-through terminal with spring connection, section: 1,5 sqmm, width: 4,2 mm, color:black | 0.005 | Заказать |
| 123756 | 8WH2000-0AF00 | feed-through terminal with spring connection, section: 0.08 - 2.5 mm2, width: 5.2 mm, color: gray | 0.005 | Заказать |
| 77251 | 8WH2000-0AF01 | feed-through terminal with spring connection, section: 0.08 - 2.5 mm2, width: 5.2 mm, color:blue | 0.005 | Заказать |
| 77252 | 8WH2000-0AF02 | feed-through terminal with spring connection, section: 2,5 sqmm, width: 5,2 mm, color:red | 0.006 | Заказать |
| 123757 | 8WH2000-0AF03 | feed-through terminal with spring connection, section: 2,5 sqmm, width: 5,2 mm, color:green | 6 | Заказать |
| 77253 | 8WH2000-0AF04 | feed-through terminal with spring connection, section: 2,5 sqmm, width: 5,2 mm, color:orange | 0.006 | Заказать |
| 123758 | 8WH2000-0AF05 | feed-through terminal with spring connection, section: 2,5 sqmm, width: 5,2 mm, color:white | 6 | Заказать |
| 77254 | 8WH2000-0AF06 | feed-through terminal with spring connection, section: 4 sqmm, width: 5,2 mm, color:yellow | 0.006 | Заказать |
| 77255 | 8WH2000-0AF08 | feed-through terminal with spring connection, section: 2,5 sqmm, width: 5,2 mm, color:black | 6 | Заказать |
| 77256 | 8WH2000-0AG00 | feed-through terminals with spring connection, section: 0.5 - 4 mm2, width: 6.2 mm, color: gray | 0.008 | Заказать |
| 77257 | 8WH2000-0AG01 | feed-through terminals with spring connection, section: 0.5 - 4 mm2, width: 6.2 mm, color: blue | 0.002 | Заказать |
| 77258 | 8WH2000-0AG02 | feed-through terminal with spring connection, section: 4 sqmm, width: 6,2 mm, color:red | 0.009 | Заказать |
| 77259 | 8WH2000-0AG03 | feed-through terminal with spring connection, section: 4 sqmm, width: 6,2 mm, color:green | 0.009 | Заказать |
| 123759 | 8WH2000-0AG04 | feed-through terminal with spring connection, section: 4 sqmm, width: 6,2 mm, color:orange | 0.009 | Заказать |
| 123760 | 8WH2000-0AG05 | feed-through terminal with spring connection, section: 4 sqmm, width: 6,2 mm, color:white | 0.009 | Заказать |
| 77260 | 8WH2000-0AG06 | feed-through terminal with spring connection, section: 4 sqmm, width: 6,2 mm, color:yellow | 0.009 | Заказать |
| 77261 | 8WH2000-0AG08 | feed-through terminal with spring connection, section: 4 sqmm, width: 6,2 mm, color:black | 0.009 | Заказать |
| 123761 | 8WH2000-0AH00 | feed-through terminal with spring connection, section:0.5 - 6 mm2, width: 8.2 mm, color: gray | 0.017 | Заказать |
| 123762 | 8WH2000-0AH01 | feed-through terminal with spring connection, section:0.5 - 6 mm2, width: 8.2 mm, color: blue | 0.017 | Заказать |
| 123763 | 8WH2000-0AJ00 | feed-through terminal with spring connection, section: 1.5 - 10 mm2, width: 10 mm, color: gray | 0.025 | Заказать |
| 123764 | 8WH2000-0AJ01 | feed-through terminal with spring connection, section: 1.5 - 10 mm2, width: 10 mm, color:blue | 0.023 | Заказать |
| 77262 | 8WH2000-0AK00 | feed-through terminal with spring connection, section: 1.5 - 16 mm2, width: 12 mm, color: gray | 0.038 | Заказать |
| 123765 | 8WH2000-0AK01 | feed-through terminal with spring connection, section: 1.5 - 16 mm2, width: 12 mm, color:blue | 0.037 | Заказать |
| 77263 | 8WH2000-0AM00 | feed-through terminaln with spring connection, section: 2.5 - 35 mm2, width: 16 mm, color: gray | 0.101 | Заказать |
| 77264 | 8WH2000-0AM01 | feed-through terminaln with spring connection, section: 2.5 - 35 mm2, width: 16 mm, color: blue | 0.094 | Заказать |
| 123766 | 8WH2000-0CE07 | pe terminal with spring connection, section: 0.14 - 1.5 mm2, width: 4.2mm, color: green-yel. | 0.009 | Заказать |
| 123767 | 8WH2000-0CF07 | pe terminal with spring connection, section: 0.08 - 2.5 mm2, width: 5.2mm, color:green-yel. | 0.01 | Заказать |
| 77265 | 8WH2000-0CG07 | pe terminals with spring connection, section: 0.5 - 4 mm2, width: 6.2 mm, color:green-yel. | 0.012 | Заказать |
| 77266 | 8WH2000-0CH07 | pe terminal with spring connection, section:0.5 - 6 mm2, width: 8.2 mm, color:green-yel. | 0.023 | Заказать |
| 123768 | 8WH2000-0CJ07 | pe terminal with spring connection, section: 1.5 - 10 mm2, width: 10mm, color:green-yel. | 0.033 | Заказать |
| 123769 | 8WH2000-0CK07 | pe terminal with spring connection, section: 1.5 - 16 mm2, width: 12 mm, color:green-yel. | 0.05 | Заказать |
| 77267 | 8WH2000-0CM07 | pe terminals with spring connection, section: 2.5 - 35 mm2, width: 16 mm, color: green-yel. | 0.11 | Заказать |
| 77272 | 8WH2003-0AE00 | feed-through terminal with spring connection, 3 connect. points, section: 0.14 - 1.5 mm2, width: 4.2 mm, color: gray | 0.007 | Заказать |
| 123779 | 8WH2003-0AE01 | feed-through terminal with spring connection, 3 connect. points, section: 0.14 - 1.5 mm2, width: 4.2 mm, color: blue | 0.004 | Заказать |
| 123780 | 8WH2003-0AF00 | feed-through terminal with spring connection, 3 connect. points section: 0.08 - 2.5 mm2, width: 5.2 mm, color: gray | 0.007 | Заказать |
| 77273 | 8WH2003-0AF01 | feed-through terminal with spring connection, 3 connect. points section: 0.08 - 2.5 mm2, width: 5.2 mm, color: blue | 0.008 | Заказать |
| 123781 | 8WH2003-0AG00 | feed-through terminal with spring connection, 3 connect. points, section: 0,5 - 4 mm2, width: 6.2 mm, color: gray | 0.011 | Заказать |
| 123782 | 8WH2003-0AG01 | feed-through terminal with spring connection, 3 connect. points, section: 0,5 - 4 mm2, width: 6.2 mm, color: blue | 0.011 | Заказать |
| 123783 | 8WH2003-0AH00 | feed-through terminal with spring connection, 3 connect. points, section:0.5 - 6 mm2, width: 8.2 mm, color: gray | 0.024 | Заказать |
| 123784 | 8WH2003-0AH01 | feed-through terminal with spring connection, 3 connect. points, section:0.5 - 6 mm2, width: 8.2 mm, color: blue | 0.023 | Заказать |
| 123785 | 8WH2003-0CE07 | pe terminal with spring connection, 3 connect. points, section: 0.14 - 1.5 mm2, width: 4.2 mm, color:green-yel. | 0.01 | Заказать |
| 77274 | 8WH2003-0CF07 | pe terminal with spring connection, 3 connect. points section: 0.08 - 2.5 mm2, width: 5.2mm, color: green-yel. | 0.012 | Заказать |
| 77275 | 8WH2003-0CG07 | pe terminal with spring connection, 3 connect. points, section: 0,5 - 4 mm2, width: 6.2 mm, color:green-yel. | 0.019 | Заказать |
| 77276 | 8WH2003-0CH07 | pe terminal with spring connection, 3 connect. points, section:0.5 - 6 mm2, width: 8.2 mm, color:green-yel. | 0.03 | Заказать |
| 123787 | 8WH2004-0AE00 | feed-through terminal with spring connection, 4 connect. points, section: 0.14 - 1.5 mm2, width: 4.2 mm, color: gray | 0.008 | Заказать |
| 123788 | 8WH2004-0AE01 | feed-through terminal with spring connection, 4 connect. points, section: 0.14 - 1.5 mm2, width: 4.2 mm, color: blue | 0.008 | Заказать |
| 77280 | 8WH2004-0AF00 | feed-through terminal with spring connection, 4 connect. points section: 0.08 - 2.5 mm2, width: 5.2 mm, color: gray | 0.008 | Заказать |
| 123789 | 8WH2004-0AF01 | feed-through terminal with spring connection, 4 connect. points section: 0.08 - 2.5 mm2, width: 5.2 mm, color: blue | 0.01 | Заказать |
| 123790 | 8WH2004-0AG00 | feed-through terminal with spring connection, 4 connect. points, section: 0,5 - 4 mm2, width: 6.2 mm, color: gray | 0.013 | Заказать |
| 123791 | 8WH2004-0AG01 | feed-through terminal with spring connection, 4 connect. points, section: 0,5 - 4 mm2, width: 6.2 mm, color: blue | 0.013 | Заказать |
| 123792 | 8WH2004-0CE07 | pe terminal with spring connection, 4 connect. points, section: 0.14 - 1.5 mm2, width: 4,. mm, color:green-yel. | 0.012 | Заказать |
| 123793 | 8WH2004-0CF07 | pe terminal with spring connection, 4 connect. points section: 0.08 - 2.5 mm2, width: 5.2 mm, color:green-yel. | 0.008 | Заказать |
| 77281 | 8WH2004-0CG07 | pe terminal with spring connection, 4 connect. points, section: 0,5 - 4 mm2, width: 6.2 mm, color:green-yel. | 0.018 | Заказать |
| 77533 | 8WH9000-0GA00 | cover segment, for f-t terminals 2.5 mm2 with spring connection, color: gray | 0.1 | Заказать |
| 77535 | 8WH9000-1GA00 | cover for feed-through term. with spring connection, section: 2.5 mm2, width: 2.2 mm, color: gray | 0.2 | Заказать |
| 123998 | 8WH9000-2GA00 | cover for feed-through term. with spring connection, 3 connect. points, section: 2.5 mm2, width: 2.2 mm, color: gray | 0.1 | Заказать |
| 77546 | 8WH9000-4GA00 | cover for feed-through term. with spring connection, 4 connect. points, section: 2.5 mm2, width: 2.2 mm, color: gray | 0.3 | Заказать |
| 124007 | 8WH9003-0GA00 | cover segment, for f-t terminals 4 mm2 with spring connection, color: gray | 0.4 | Заказать |
| 77560 | 8WH9003-1GA00 | cover for feed-through term. with spring connection, section: 4 mm2, width: 2.2 mm, color: gray | 0.1 | Заказать |
| 124011 | 8WH9003-2GA00 | cover for feed-through term. with spring connection, 3 connect. points, section: 4 mm2, | 0.4 | Заказать |
| 124013 | 8WH9003-4GA00 | cover for feed-through term. with spring connection, 4 connect. points, section: 4 mm2, | 0.3 | Заказать |
| 124016 | 8WH9004-1GA00 | cover for feed-through term. with spring connection, section: 6 mm2, width: 2.2 mm, color: gray | 0.3 | Заказать |
| 77565 | 8WH9004-2GA00 | cover for feed-through term. with spring connection, 3 connect. points, section: 6 mm2, width: 2.2 mm, color: gray | 0.5 | Заказать |
| 124020 | 8WH9005-1GA00 | cover for feed-through term. with spring connection, section: 10 mm2, width: 2.2 mm, color: gray | 0.6 | Заказать |
| 77567 | 8WH9006-1GA00 | coverfor feed-through term. with spring connection, section: 16 mm2, width: 2.2 mm, color: gray | 0.7 | Заказать |
| 124085 | 8WH9060-5AA06 | warning cover for operation shafts with spring connection width: 5,2mm color: yellow | 0.03 | Заказать |
| 77623 | 8WH9061-5AA06 | warning cover for operation shafts with tension spring connection width: 4,2mm color: yellow | 0.03 | Заказать |
| 77624 | 8WH9063-5AA06 | warning cover for operation shafts with tension spring connection width: 6,2mm color: yellow | 0.04 | Заказать |
| 77625 | 8WH9064-5AA06 | warning cover for operation shafts with tension spring connection width: 8,2mm color: yellow | 0.09 | Заказать |
| 124086 | 8WH9065-5AA06 | warning cover for operation shafts 10mm2 width: 10mm color: yellow | 0.2 | Заказать |
| 77626 | 8WH9066-5AA06 | warning cover for operation shafts 16mm2 width:16mm color: yellow | 0.2 | Заказать |
| 124087 | 8WH9067-5AA06 | warning cover for operation shafts 35mm2 width: 35mm color: yellow | 0.4 | Заказать |
| 124088 | 8WH9070-0AA00 | compartment partition for optical and electrical isol. from terminal groups, with sections up to 4 mm2, width: 2 mm, color: gray | 0.2 | Заказать |
| 124089 | 8WH9070-0DA00 | compartment partition for optical and electrical isol. from terminal groups, with sections up to 6 mm2, width: 2 mm, color: gray | 0.7 | Заказать |
| 124090 | 8WH9070-0GA00 | compartment partition for optical and electrical isol. from terminal groups, with sections up to 4 mm2, 3 connect. points, width: 2 mm, color: gray | 0.5 | Заказать |
| 124091 | 8WH9070-0HA00 | compartment partition for optical and electrical isol. from terminal groups, with sections up to 4 mm2, 4 connect. points, width: 2 mm, color: gray | 0.5 | Заказать |
