Ordering licenses for runtime software производства Siemens

Runtime licenses for SIMOTION C, D

Licenses for runtime software for SIMOTION C, D can be ordered individually or pre-installed (by order code/Z option) on memory card.

In both cases, the license certificate is enclosed.

Runtime licenses for SIMOTION P

Licenses for runtime software for SIMOTION P can be ordered individually or by means of order code (Z option).

When ordered by means of order code (Z option), the runtime licenses are not pre-installed in this case, the license certificate is enclosed.

Exception:

When the MultiAxes Package license for SIMOTION P350-3 is ordered by way of order code M35, the license is pre-installed on the system.

Ordering individual licenses

The order numbers can be found in column "Single-user license" in the selection and ordering data table.

If several licenses of the same type are needed, e.g. 3 x POS license, the order number must be repeated for each license.

Example:

A 1 GB CompactFlash card for SIMOTION D4x5-2 has been purchased, but without pre-installed runtime licenses. During the configuring process with SIMOTION SCOUT, a message is displayed to indicate that the following runtime licenses are needed: 1 x POS axis license, 1 x TControl license.

The table of selection and ordering data provides:

• POS axis license: 6AU1820-1AA20-0AB0
• TControl license: 6AU1820-2AA20-0AB0

Ordering pre-installed licenses

To order pre-installed licenses, the type and number of the required licenses must be specified in the order using order codes (Z options). These order codes are added to the order number for the memory card.

Step 1: Specifiy the order no. of the SIMOTION memory card first:

• Memory card for SIMOTION C:
  Micro Memory Card 64 MB: 6AU1720-1KA00-0AA0
• Memory card for SIMOTION D410, D4x5:
  CompactFlash Card 1 GB: 6AU1400-2PA01-0AA0
• Memory card for SIMOTION D4x5-2:
  CompactFlash Card 1 GB: 6AU1400-2PA21-0AA0

Step 2: The following order codes specify the type and number of the required runtime licenses:

The order codes are indicated by means of “-Z“ and can be found in column “Order codes for pre-installed licenses” in the selection and ordering data table.

Example 1:

Micro Memory Card 64 MB for SIMOTION C240 with

• MultiAxes Package license
  for SIMOTION C2xx:

Order No.: 6AU1720-1KA00-0AA0 -Z M24

Example 2:

CompactFlash Card 1 GB for SIMOTION D4x5-2 with

• 3 POS licenses,
• 2 CAM licenses,
• 1 TControl license and
• 1 Safety Integrated Extended Functions license:

Order No.: 6AU1400-2PA21-0AA0 -Z P03 C02 T01 F01

Configurator for runtime licenses

An electronic ordering configurator is available in the Industry Mall for ordering SIMOTION hardware with corresponding runtime licenses.

Homepage: http://www.siemens.com/industrymall

This will guide you step by step through the process of selecting and ordering SIMOTION hardware with pre-installed runtime licenses.

Selection and ordering data

¹⁾ Requires a license for SIMOTION Kernel < V4.2
